Specifications

swap_vert

Reading Range

  • -30 to +80 °C (-22 to +176 °F)

Accuracy

  • ±1 °C (1.8 °F)
settings_ethernet

Measurement Frequency

  • Once every 15 mins (for 2 month of data)
wifi

Wireless Signal Range

  • Up to 8 meters*
  • Up to 26 feet*
crop_free

Dimensions

  • 38 x 38 x 12 mm (1.5 x 1.5 x 0.5 inches)
swap_calls

Temperature Cable Length

  • 40cm (16 inches)/ 3m (10 feet)
battery_charging_full

Battery Life

  • Up to 4 months after installation
sync

Data Communication and Analysis

  • Android and iOS mobile app
  • Giatec 360 Cloud Dashboard
assignment

Standards

  • ASTM C1074 (Approved by ACI 318, CSA A23.1, most of USDOT specifications)

FAQs

add_circle
How long is the battery life?
The battery life is about 4 months under room temperature.
add_circle
Do MTO and DOTs allow this method of concrete strength measurement?
The strength estimation according to the concrete maturity method as described in the ASTM C1074 has been specified by many DOTs in the US as well as the CSA. Here is the clause from CSA:

"4.4.6.4.5 In-place strength
4.4.6.4.5.1 Test procedures
Unless otherwise specified by the owner, the in-place strength shall be determined in accordance with CSA A23.2-14C, CSA A23.2-15C or ASTM C1074 for the purposes of determining:
(a) when forms shall be removed or when prestressing or post-tensioning shall be applied; (b) when curing shall be terminated; and (c) when re-shores shall be removed."

add_circle
What are the wires sticking out of the SmartRock?
You will find two short metal wires and a slightly longer black wire sticking out of the SmartRock device. The end of the black wire is the temperature sensor, while the two short metalic wires are used to activate the sensor and to secure it to the rebar.
add_circle
What is the maximum depth I can place the SmartRock?
We recommend a maximum depth of 5cm (2 inches) to ensure that the signals from the sensor are strong enough. The signal strength weakens as you place the sensor deeper.
add_circle
Can I get SmartRock with longer thermocouple cables?
Yes. Please ask for customized length when you are ordering your SmartRock package. You can get this cable as long as 10 ft.
